Pixel Technologies AFHD-4 AM FM HD Radio Antenna works with Coaxial RG6 Cable, Omnidirectional and Long Range Antenna, Attic or Outdoor Installation

Product description

The Pixel AFHD-4 antenna delivers best in class AM/FM & HD Radio reception over a single RG-6 cable. Designed for easy outdoor or attic installation with rugged pro-quality construction, this low profile Omni-directional antenna will bring out the best performance from any receiver.

Product Overview


Frequency of Operation: AM Band 500 KHz to 1750 KHz, FM Band 88MHz -108 MHz


Ground plane required: None


AM/FM dB Gain: 4.5 dB Gain


AM capture length: 300 inches


FM rejection in AM band: > 50 dB


AM rejection in FM band: > 60 dB


AM/FM Pass-band loss: < 1dB


AM load impedance: 300 ohms


FM load impedance: 75 ohms


Antenna Beam Width: Omni-directional


Daytime Reception: FM Stereo 80 Miles, FM HD 50 Miles, AM (Mono) 90 Miles, AM HD 50 Miles

U Bolts Inside Dimensions:  2 inches

Reception Performance: These results will vary as function of the antenna's height above ground, the power of transmitting station, the transmitter's antenna beam pattern, the local terrain and the quality of the receiver utilized.
Technical Specs


Model #: AFHD-4


Manufacturer: Pixel Technologies


Dimensions: 48 inches tall


Weight: 3 lbs


Package Includes


(1) AM / FM antenna


(1) L-mounting bracket


(1) Weather boot


(1) Surge protector


(2) 20 dB attenuator


(2) 10 dB attenuator


(2) 1ft RG-6 cables


(1) AM/FM band separator


(2) U bolts with washers and nuts


(2) Pole mount saddle brackets


(4) Mounting screws with plastic inserts


(1) F-Female to twin lead adapter


Warranty

1 Year Warranty (Parts & Labor)

Product Documentation, Installation Guides & Manuals


Pixel AFHD-4 Manual (PDF)
