Pocket Science Lab Dev Board

Product description

What's included
1 x Pocket Science Lab
Specification

4-Channel up to 2MSPS Oscilloscope. Software selectable amplification stages
12-bit Voltmeter with programmable gain. Input ranges from +/-10 mV to +/-16 V
3x 12-bit Programmable voltage sources +/-3.3 V,+/-5V,0-3 V
12-bit Programmable current source. 0-3.3 mA
Supports Advanced Plugins/Add-on Modules
4-Channel, 4 MHz, Logic Analyzer
2x Sine/Triangular wave generators. 5 Hz to 5 KHz. Manual amplitude control for SI1
4x PWM generators. 15 nS resolution. Up to 8 MHz
Capacitance Measurement. pF to uF range
I2C, SPI, UART data buses for Accel/gyros/humidity/temperature modules etc


Features List
Oscilloscopes
One of the main features of PSLab is the 4-channel Oscilloscope which can monitor analog inputs at maximum of 2 million samples per second. It includes controls such as triggering, and gain selection. Uses Python-Scipy for curve fitting.
Waveform Generators

SI1 : 5 Hz – 5 KHz arbitrary waveform generator. Manual amplitude control up to +/-3 Volts
SI2 : 5 Hz – 5 KHz arbitrary waveform generator. Amplitude of +/-3 Volts. Attenuable via software
SQx : There are four phase correlated PWM outputs with maximum frequency 32 MHz, 15 nano second duty cycle, and phase difference control.


Measurement Functions

Frequency counter tested up to 16 MHz.
Capacitance Measurement. pF to uF range
PSLab has several 12-bit analog inputs (function as voltmeters) with programmable gains, and maximum ranges varying from +/-5 mV to +/-16 V.


Voltage and Current Sources

12-bit Constant Current source. Maximum current 3.3 mA (subject to load resistance).
PSLab has three 12-bit Programmable voltage sources +/-3.3 V,+/-5 V,0-3 V. (PV1, PV2, PV3) controls


Other useful tools

4MHz, 4-channel Logic analyzer with 15 nS resolution.Voltage and Current Sources
SPI, I2C, UART outputs
Graphical Interfaces for Oscilloscope, Logic Analyser, streaming data, wireless acquisition and several experiments developed that use a common framework which drastically reduces code required to incorporate control and plotting widgets.
PSLab also has space for an ESP-12 module for WiFi access with access point/ station mode.


Advanced Controls

Advanced Controls with Oscilloscope
Data Logger
Logic Analyzer


Data Sheet
Find the complete data sheet here:

PSLab-Data-Sheet
