A01-Microsmt PNPv3 - for OPENPNP

Product description

Tips 1:  Starting from September 2024, purchasing pnpV3 will allow you to buy up to 30pcs Bing feeders at a 50% discount.
Tips 2：If you choose  the cheap DPD logistics to ship to the EU, we can pay the customs duties and VAT for you，DPD is usually 2 weeks later than DHL, FedEx, and UPS.
Tips 3:  The feeder in the picture is only a demonstration, and you need to purchase it separately.
Tips 4:  All 3D printing accessories require you to print them yourself.


Product parameters
Material: aluminum alloy --except for green 3D printing accessories
Total size：L630mm*W640mm*H40mm
Platform size: 500mm*255mm
Length of x-axis linear  guide: 500mm
Length of y-axis linear  guide: 540mm
Net weight: 15kg
Power supply:24V ,14.5A
Input voltage: AC110V/220V
This  machine  is  fit  for    Bing  feeder   and  0816  feeder, Bing feeder is recommended



Pack  list

1:  PNPmachine-V3   a  set    ( The motherboard is microsmt  pnpboard V1.7)
    1.1   Mounting Head （belt structure-for juki nozzle)   1pcs
    1.2   A02 Aluminum frame  1pcs
    1.3   Pnpboard  V1.7  1pcs
    1.4   Demo Board PCB  1pcs
    1.5   Bottom USB camera   1pcs
    1.6   Top USB camera   1pcs




     1.7   Tank chain   2pcs




    1.8   Belt   6M
    1.9   X-axis  motor  1pcs
    1.10   Y-axis  motor  1pcs
    1.11   Vacuum pump   1pcs
            Solenoid valve    2pcs
    1.12   MW  24VDC  14.5A  power supply   1pcs
2:  CP45  nozzle  a  set
3:  Bing  feeder  controller *1 ( mega2560  board)
The goods you will receive are as follows, which need to be assembled by yourself
​ ​
 ​ ​
