Newly

Mini Brass Hot Plate Preheater with USB-C PD or DC

Product description

The new version of the Mini Hot Plate, MHP50, offers an increased heating power of 1.5x~2.5x compared to its predecessor, the MHP30. This results in faster heating and a larger rework area for added convenience.
The Mini Brass Hot Plate Preheater features USB-C PD at 20V for 100W or 20~24V DC for 150W, making it suitable for heating small PCBs for desoldering or rework. This upgraded version includes a larger 5x5cm brass hot plate with a heat-resistant coating, a lower center of gravity for stability, and a color TFT display. It also offers two input power options, making it a versatile and practical choice for DIY enthusiasts and professionals alike.
This portable Mini Brass Hot Plate Preheater is an optimal choice for efficient and speedy heating, reaching 300ºC in just 150 seconds from room temperature. The mini-tower-shaped controller boasts a color LCD display and two buttons, along with useful features such as preset temperature, tilt protection, power wake-up, and automatic sleep. These smart modes are complemented by an LED that changes color as the temperature rises, making it a practical tool for professionals and experts in the industry.
We use ours to reflow small PCBs with solder paste, or to rework boards by heating them up so we can easily remove or re-align components.
Kit includes:

MHP50 Controller and Hot Plate
Silicone USB C Cable (20V 5A) Note that a 20V 5A USB PD power supply is not included! You'll need to pick up a 100W 'laptop' power supply with USB type C PD support, if you don't have one.
User manual









Technical Details


Specifications:

Heating surface area: 50mm x 50mm
Temperature range: 100-350ºC
Temperature stability: ±3%
Input voltage (use only one input): DC 19-24V / PD 20V
Max power: DC5525 12-24V 150W or PD 20V 100W


Specification Sheet
User Manual
