OCTO Pro 44 Watt Laser with Air Assist

Product description

Get CO2 level power on your MillRight CNC router with this powerful laser attachment. This JTECH laser combines EIGHT laser diodes to output 44 watts of focused laser power!

Engrave on wood, leather, acrylics, and many other materials
Cut plywood, MDF, solid wood, and colored acrylics.
Cut many types of foam and plastics (NEVER laser cut vinyl based plastics due to toxic offgassing!)
Burn away powdercoat, paint, and anodized finishes from a metal piece. It is not intended to cut metal.
MAKE incredible objects for projects or production. Your creations are only limited by your imagination!
Even More Cutting Power
This OCTO Pro laser has the most cutting power of any diode laser we've found! With 44 watts of optical power (real, measured power, not "input power" like those Chinese lasers advertise!) and the air assist engaged, you can make some serious laser cuts. See the expected cutting speeds below.

3/4" solid pine at 6 IPM, single pass
1/4" plywood at 20IPM, single pass
1/8" plywood at 30 IPM, single pass
1/16" plywood at 60 IPM, single pass
1/2" colored acrylic at 8 IPM, 3 passes
1/8" colored acrylic at 15 IPM, single pass

This laser can cut and engrave woods, colored acrylic, other plastics (do NOT cut a Vinyl based plastic!), leather, and other materials. It can also burn powdercoat, paint, and anodized finishes from a metal piece. It is not intended to cut metal.
Safety features to protect yourself and others:
Key Switch – This key is needed to enable the laser.  When the key switch is turned on, the laser is enabled and the key CANNOT come out. You can only remove the key when it is disabled. This feature is good if you have curious children or have your laser in a shared area and want to limit use. Just take the key out and hide it!

Remote Interlocks – This feature allows for the addition of switches to your enclosure so when it is open, the laser will automatically turn off. Also provides for the addition of an EStop button for the laser, which is always good for if you need to stop the laser super quick!  Add as many switches as you want to make a super safe area for your laser machine so nobody can accidentally look into the laser.

Power Fault Protection – This one may seem like it is not needed, but hear us out.  Consider your power goes out in your area where the laser is located.  You were running your program and then everything is dark…Power doesn’t come back on for awhile… long enough for you to forget that the laser was left ON! You come back and are checking your laser and boom, the power is back on, right when you are looking straight at it. Well, don’t worry because the laser will be disabled whenever the power to the driver is lost. Press the reset button and you are back in action!

Emission Indicator –  LED on the front to let you know you’re really super bright laser is on.

Angle Sensor –  This feature prevents the laser from firing if its tilted past 45 degrees, so it will shut off if it breaks away from the head in a crash.
Low Power Adjustment for Beam Placement
The OCTO PRO 44W laser has a lot of power.  But when you want to find the center position on your workpiece, you don’t want it to burn a hole in your wood before you even start engraving. So, we have included an adjustable low power mode into the safety interface board to allow for precise control over the power setting.  Now, when you fire your laser at 1%, it won’t burn your project.




What this kit includes:
The standard kit comes with:

44W OCTO laser diode head with magnetic shroud
Laser Diode Drive
Laser shroud
Power Adapter 24V
Power Extension
Laser Safety Goggles for 445nm Lasers
Molex MiniFit Jr. Input Cable
Laser Focus Gauge
Air Assist Nozzle and 12' of air hose (pump not included. 50W aquarium air pump recommended)


Specifications
Laser Head



Maximum Laser Optical Power
44W


Laser Spot
0.08mm*0.1mm


Wavelength
455± 5nm


Integrated Safety Feature
Angle sensor, 45 degree


Operating Temperature:
5 to 40 °C


Storage Temperature:
1 to 45 °C



Interface Board



Protection:
Soft Start, Reverse Voltage, Current Limit, Thermal Shutdown


Integrated Safety Features
Laser Enable Key Switch, Integrated Laser Interlock, Power off Reset, LED Indicators


AC Adapter Input Voltage:
100 – 240 VAC


Control Signal Digital Isolation Voltage:
4500 Vrms


Minimum Control Signal ”Turn On” Voltage:
2.8 Volts


Control Signal Maximum Voltage:
24Volts


Control Signal Maximum Current:
50 ma


Control Signal Maximum Frequency:
2.5KHz


Connectors:
Screw Terminal and Molex Mini-Fit Jr™ Connectors


Operating Temperature:
0 to 40 °C


Storage Temperature:
-40 to 70 °C
